DPK’s Topographic, As Built, and Environmental Easement Surveys help Environmental Consultants Achieve Regulatory Compliance, Future Property Use Data, and Contribute to Successful Land Conservation
DPK Consulting was recently contracted to perform a series of topographic field and As-Built surveys at the former soft drink Plant in New York State. These surveys were crucial in documenting the completion of a remedial system installation. Additionally, DPK was tasked with preparing an Environmental Easement for two properties within the Remedial Action Area. The site, currently operating as a bottle redemption facility, presented challenges due to the high volume of bottles and cans in the facility, rendering some areas inaccessible. DPK was responsible only for the accessible areas inside and outside the site and ensuring compliance with all health and safety requirements to operate as a direct subcontractor for their environmental consulting customer.
Specific Tasks
- Site survey with well location data
- Post-Construction As-Built Survey
- Environmental Easement
Scope of Work
Utilizing a previous survey to establish benchmarks, DPK was assigned to produce a current monitoring and Soil Vapor Extraction (SVE) wells location survey. Many wells from the prior survey were inaccessible. DPK provided horizontal and vertical positions, PVC riser data within each well, and elevation data from the center of the flush-mount casing covers of all wells.
In addition to the well location survey, DPK delivered an As-Built survey encompassing the following site features:
- Remediation System Container
- Newly Installed Chain-Link Fence (sections and gates)
- Four System Stub-Ups for Horizontal Wells
- Three System Inlet Locations
- Remediation System Stack
NYSDEC mandated an Environmental Easement detailing the two remedial action areas. DPK’s deliverable included:
- Metes and Bounds Descriptions
- Graphic Scale
- Tax Map Section, Block, and Lot
- Surveyor Boundaries
- Property Assets (buildings, monuments, overlaps/encroachments)
- Visible Improvements within 5 ft. of boundary lines
- Natural Bodies of Water (ponds, lakes, springs, rivers)
DPK’s internal systems team developed AutoCAD electronic files and final maps to fulfill these requirements.
